Ever wonder what the data on your scan tool should be? Maybe mass air flow data or VANOS? Even idle control data is sometimes displayed in a format not easily deciphered.
The Schwaben BMW/MINI scan tool is the most cost-effective professional scan tool for enthusiasts, small garages, independent repairs, specialized garages and technicians by delivering OE-level diagnosis on all the electronic systems. It does not only include basic functions such as codes and live data, but also is capable of advanced functions.
- An inexpensive scan tool, the MAOZUA V7.7 Creator C310+ BMW Scan Tool / Code Reader is designed to work with all BMW models launched after 2000. While this tool doesn’t offer as many features as some other scan tool, it still allows you access to lots of live diagnostic data and allows you to clear trouble codes.
- Best BMW Scan Tools Review. Foxwell NT510 Elite BMW Scan Tool. One of the best purchases I have ever made. It was easy to use and saved me over 2K in labor and repairs from the dealership! The Foxwell NT510 is a standalone BMW code reader that has a lot of functions for diagnostic and resetting.
- ProTool by BimmerGeeks puts the power of a BMW specialist in the palm of your hand. Transform your android device into one of the most powerful scan-tools available for BMW. ProTool is a feature-rich, easy to use Android app that turns even the most novice of users into BMW experts. Complex software and special equipment are no longer necessary.
This technical article defines BMW scan tool data stream desired DME data, as set by BMW. BMW calls this data set point data. This refers to the idea that these sensors (inputs) and controls (outputs) should be within this range when normal. Outside of these ranges can be considered faulty and furhter diagnosis to reach the root cause is needed.
Engine m52 SW MS42---- example from 2000 528
Additive -0.35ms to 0.35ms
Multiplicative -7% to 11%
Idle speed regulation -7.5% to 7.5%
Bmw Scan Tool 1.4 Inpa Driver
Engine M54 SW MS43 2001 525
Idle adaption -7.5 to 7.5%
O2 controller 0.8 to 1.2
Air mass 8 to 15 kgph
Injector duration 1.83.4 ms
Smooth running
- <2.5 ok
- 2.5 to 7.0 critical
- >7.5 not ok
Lambda idle additive -3.5 to 3.5ms
Part load multiplicative -7 to 11%
Engine M54 offrd 2004 x3 2.5
Air mass 8 to 15 kgh
Inject duration 1.8 to 3.4 ms
Load 80 to 140 mg/stroke
Engine M54 ms43 2002 330i
Idle air adaptation -7.5 to 7.5%
Air mass 9 to 16 kgh
Injector duration 1.8 to 3.4ms
Additive fuel trim -0.35 to 0.35 ms
Multiplicative fuel trim -7 to 11%
Engine M53 ms43 2003 325xit
Idle adaptation -7.5 to 7.5%
Air mass 8 to 15 kg/h
Injector duration 1.8 to 3.4ms
Load signal 80 to 140mg/stroke
Idle actuator opening 23 to 39%
Intake cam 110° to 115°
Exhaust cam -107.5° to -102.5°
Additive -0.35 to 0.35ms
Multiplicative -7 to 11%
Idle adaptation deviation 0 to 0.25
Part load adaptation deviation 0 to 0.25
Pwg1 0.58 to 0.81v
Pwg2 0.17 to 0.49v
Dk pot1 0.29 to .81v
Dk pot 2 4.15 to 4.75V
Engine M54 2003 525i tu
Smooth running same as previous
Rpm 680 to 800
Idle air adaptation -7.5 to 7.5%
Air mass 8 to 15 kg/h
Injector duration 1.8 to 3.4ms
Idle actuator opening 23 to 39%
Intake cam 100° to 115°
Exhaust cam -107.5° to -102.5°
Additive -0.35 to 0.35ms
Multiplicative -7 to 11%
Idle adaptation deviation 0 to 0.25
Part load adaptation deviation 0 to 6
Pwg1 0.58 to 0.81v
Pwg2 0.17 to 0.49v
Bmw Scan Tool App
Dk pot 1 0.29 to 0.81v
Dk pot 2 5.15 to 4.75v
Engine M54 ms45 2003 Z4
Smooth running see previous
Rpm 680 to 800
Air mass 8 to 15kg/h
Injector duration 1.8 to 3.4
Load 80 to 140mg/stroke
Adaptation idle speed -7.5 to 7.5%
Additive -0.35 to .35ms
Multiplicative -7 to 11%
Intake cam 110° to 130°
Exhaust cam -114° to -96°
Pwg1 0.58 to 0.81v
Pwg2 0.17 to 0.49v
Dk pot 1 0.29 to 0.81v
Dk pot 2 4.15 to 4.75v
Engine M52 ms42 2000 528 engines greater than 2.0 liter
Smooth running same as above
Engine rpm 680-800
Ignition angle -3° to 3°
Idle air adaptation -7.5% to 7.5%
Air mass 8 to 16 kg/h
Injector duration 1.8 to 3.4ms
Load 80 to 140 mg/stroke
Idle actuator opening 23 to 39%
Intake cam 110° to 115°
Exhaust cam -107.5° to -102.5°
Additive -0.35 to 0.35ms
Multiplicative -7 to 11%
Idle adaptation deviation 0 to 0.25
Part load adaptation deviation 0-6
Potentiometer cable pulleys
- Pulley1 13 to 27*
- Pulley2 13 to 27*
Mdk1 10° to 32°
Mdk2 10° to 32°
M52 2.0l ms42 euro engine
RPM 680 to 800
Ignition angle 0° to 8°
Idle air adaptation -7.5 to 7.5
Air mass 7 to 13 kg/h
Injector duration 1.5 to 3ms
Load signal 60 to 140 mg/stroke
Idle actuator opening 23 to 39%
Intake cam 110° to 115°
Exhaust cam -107.5° to 102.5°
Additive -0.35 to 0.35ms
Multiplicative -7 to 11%
Idle adaptation deviation 0 to 0.25
Part load adaptation deviation 0 to 6
Potentiometer cable pulleys
- Pulley1 13° to 27°
- Pulley2 13° to 27°
Mdk1 10° to 32°
Mdk2 10° to 32°
Engine S62 MSS52 2002 M5
Additive -0.25ms to 0.25ms
Multiplicative -15% to 15%
O2 control factor Min .85 Max 1.15
Engine M62 lev me7.2 2000 540
Additive -0.3 to 0.3 ms
Multiplicative -20 to 20%
